Composite Plates
I-C-P base product is continuous fiber reinforced plates. I-C-P mainly uses high fiberglass content Woven Roving Compofil with Polypropylene matrix in a worldwide unique continuous thermoplastic process.
In extended manufacturing process the plates could be used as skin (face sheet) of sandwich panels.
Continuous Fiber Reinforced Thermoplastic Plates
I-C-P produces high-performance continuous fiber-reinforced composite plates using a unique, continuous thermoplastic process that is unmatched worldwide.
Our plates are engineered with high-fiberglass content Woven Roving Compofil and a polypropylene (PP) matrix, resulting in strong, durable sheets with excellent impact resistance.
Thanks to the thermoplastic nature of the material, these plates can be reheated and thermoformed multiple times without degrading their mechanical properties, giving you unmatched flexibility for downstream fabrication.
- Material Composition: Continuous woven roving fiberglass reinforcement with a polypropylene thermoplastic matrix.
- High Strength & Durability: Engineered for heavy-duty applications with excellent mechanical performance.
- Thermoplastic Advantage: Reheat, reshape, and reuse without loss of performance.
- Thermoforming Capability: Easily formed into custom shapes using heat and pressure.
- Wide Application Potential: Ideal as face sheets (skin layers) in sandwich panel constructions or composite products formed.
-
Available Sizes:
Thickness: 0.5 mm (1/32″) up to 6 mm (1/4″). Standard Widths: 1230 mm (4′) and 2450 mm (8′).
Length: Unlimited
| Code | Total Thickness (in mm) | Total Thickness (in mm) | Weight (lb/sft (kg/SM)) | Complementary |
|---|---|---|---|---|
| PLT4 | 0.16″ – (4) | 96″ x 192″ – (2440 x 4880) 96″ x 264″ – (2440 x 6700) | 1.20 (5.8) | Both sides UV & water-resistant, white color finishing |
| PLT5 | 0.2″ – (5) | 96″ × 264″ (2440 × 6700) 96″ × 192″ (2440 × 4880) | 1.66 – (8.1) | Both sides UV & water-resistant, white color finishing |
| PLT2-FR | 0.08″ – (2) | 48″ x 96″ – (1220 x 2440) | 0.75 – (3.7) | UV & water resistance Orange color, Diamond antislip finishing |
| Customized Cut with Additional Fee | ||||
